Dry air capacity: 100 m³/h
Dry air dew point: -50°С
Dry air pressure: 0.18 bar
Max dry air temperature: 90±15°С
Adsorbent load: 190 kg
Number of adsorbers cartridges: 1
Zeolite regeneration temperature: 430°С
Air heater power: 24 kW
Power consumption:
- Air drying (normal operating mode): 1 kW
- Regeneration adsorbent in one cartridge: 25 kW
Electric power supply parameters: fully customizable
Output air temperature for regeneration of adsorbent in external equipment: 430°С
Dimensions (LxWxH): 1350x800x1700mm
Weight: 550 kg
