Grandway GPON SFP
GPON ONT emulation: Grandway GPON SFP
Optical interface: SC/APC or SC/UPC
Standard:
Comply with g.984.1/2/3/4 GPON standard
Comply with g.988 OMCI standard
Test result: OLT PON ID, OLT Tx power, ONT Rx power, ODN loss, ONT activation status
Others:
VFL:
Output power: 10mw
Working wavelength: 650±10nm
Working mode: CW/2Hz
OPM :
Calibrated wavelength: 850/1300/1310/1490/1550nm
Testing range:-70~+10dBm
Optical interface:
1*SC PON port
1*2.5mm universal OPM port
1*2.5mm universal VFL port
Wireless: WiFi connection with Android phone
Power supply: 6700mAh lithium battery
Working temp: 0~45℃
Dimension: 175x94x46.5mm
Weight: 577g
