Number of channels:
- Module 8 analog inputs: 16 analog channels + 16 logic channels (standard)
- Module 5 analog inputs + 3 logic inputs: 10 analog channels + 64 logic channels (standard 16 channels + 48 logic channels)
Measuring range (20 div full-scale):
- 5 mV to 20 V/div, 12 ranges, resolution: 1/100 of range (using 8966)
- 5 mV to 50 V/div, 5 ranges, resolution: 1/1 000 000 of range (using MR8990)
- 200 mV to 50 V/div, 8 ranges, resolution: 1/1600 of range (using U8794)
Maximum input voltage: 400 V DC (using the 8966/8968), 500 V DC (using the MR8990), 1000 V DC (using the U8974)
Frequency characteristics (-3dB): DC to 5 MHz (using the 8966), DC (using the MR8990), DC to 100 kHz (using the U8794)
Recording function: MEMORY (high-speed recording), RECORDER (real-time recording), X-Y RECORDER (X-Y real-time recording), FFT
Other functions: Save waveforms (in memory or FFT)
Memory storage:
MR8847-51:64 M-words
- 32 MW/ch (using 2 Analog channels), up to 4 MW/ch (using 16 Analog channels)
Storage format: CF card slot (standard) ×1 (up to 2GB, FAT, or FAT-32 format), SSD (128 GB, optional), USB memory stick (USB 2.0)
Thermal printing: 216 mm (8.50 in) × 30 m (98.43 ft), printing speed: Max. 50 mm (1.97 in)/s
LCD screen: 10.4 inch TFT (SVGA, 800×600 dots)
Language options: English, Japanese, Korean, Chinese
Supply:
- 100 to 240 V AC, 50/60 Hz
- 10 to 28 V DC (additional purchase option 9784)
Dimensions: 351 mm (13.82 in) W × 261 mm (10.28 in) H × 140 mm (5.51 in) D, 7.6 kg
Accessories: User manual × 1, measurement guide × 1, application disc (Wv wave view, communication) × 1, test lead × 1, wire label × 1, USB cable reel × 1, printing paper × 1 , paper roll x 1, Ferrite clamp ×1
