Huazheng HZ5374 High Current Generator (4000A)

Input voltage: AC380V ±10%

Power: 40KVA

Output current: AC0～4000A stepless adjustable, panel with digital display ammeter

Output voltage: > 10V

Output waveform: The output current is a standard sine wave with small glitches, which is better than the power system requirements index standard, and the ripple

coefficient is less than 0.3%. Standard sine wave.

Measurement accuracy: (Using 0.2S grade material) The actual is about 0.3; eachcurrent can be smoothly and continuously adjusted, the accuracy is higher than 0.5. Thecurrent and voltage meter shows true and effective value, high accuracy and high stability.

Output current mode: true effective value is continuously adjustable;

Current stability: 0.2%

Structural form: one

Wiring method: according to requirements

Current stability: 0.2%;

Protection settings: overcurrent and overvoltage
