HUBER+SUHNER 1399.17.0243 야외 안테나

Gain: 3.5 dBi, 4.5 dBi, 5 dBi, 5.5 dBi

VSWR: 1.8:1, 2:1

Style: Dome

Height: 33.2 mm

IP Rating: IP69

Impedance: 50 Ohms

Cable Type: SUCOFORM_122_LA_CU_CMP

Application: Cellular, WiFi

Cable Length: 0.28 m

For Use With: Small Cells

Polarization: Vertical

Mounting Style: Bracket Mount

Electrical Type: MIMO

Number of Bands: 5 Band

Mechanical Style: Module

Maximum Frequency: 5.975 GHz

Minimum Frequency: 1.71 GHz

Termination Style: Connector

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 55 C
