HV HIPOT OVT-100K Insulation Oil Tester (100kV)

Output Voltage: 0-100kV

Capacity: 1.5kVA

Measurement Accuracy: ±3%

Boosting Speed: 2.0～3.5kV/S

Settling Time: 0-15min

Boosting Interval: 0-5min

Number of Boosts: 1-6

Voltage Distortion Rate: <3%

Power Supply Voltage: AC220V±10% 50Hz±1 Hz

Dimensions: 468×384×423mm

Operating Temperature: 0℃-45℃

Operating Humidity: <75%RH

Electrode gap: standard 2.5mm or 2.0mm
