HV HIPOT OVT-80K Insulation Oil Tester (80kV)

Output voltage: 0~80kV

Voltage distortion rate: <3%

Boost speed: 0.5~5.0kV/S (adjustable)

Standby time: 15 minutes (adjustable)

Boost interval: 5 minutes (adjustable)

Number of voltage boosts: 1 to 6 times (optional)

Booster capacity: 1.5kVA

Measurement accuracy: ± 3%

Power supply voltage: AC220V± 10% 50Hz± 1 Hz

Power: <200W

Applicable temperature: 0℃ ～45℃

Applicable humidity: <75%RH

Overall dimensions: 465× 385× 425

Electrode gap: standard 2.5mm
