Continuous power (Kw/KVA): 48/60
Reserve power (KW/KVA): 53/66
Frequency (Hz): 50
Voltage (V): 230/400
Current (A): 86.6
ATS connection port: Yes
Fuel tank (L): 180
Running time at 100% CS load (h): 11
Noise level 7m away (dBA): 70
Overall weight (kg): 1160
Dimensions L×W×H (mm): 2500x950x1250
Capacity (KW/1500 million/mn): 60
Rotation speed: 1500 V/Ph
Speed adjustment: Mechanical
Cooled by water and fan
Cylinder capacity (L): 4.4
Cylinder number/model: 4L
ĐKxHC Pistion: 105×125
Compression ratio: 17.5:01
Lubricating oil capacity (L): 11
Coolant capacity (L): 14.73
Fuel consumption at 100% load (L/h): 16.1
Battery (Ah): 1x12V-16.8Ah
Continuous capacity (KVA): 60
Number of phases: 3 phases
Power factor (Cosφ): 0.8
Voltage regulation: Automatic AVR with AS440
Protection level: IP23
Insulation level: Class H
Excitation system: Automatic
Control panel: ComAp MRS 10
Current intensity indicator: Yes
