FOV : 49*41mm
Resolution: 20um
Camera: 5M
Light: RGB + W light, 4 color integral
Inspection Speed: 0.23sec/FOV
Mixing PCB inspection: Support calling program automatically.
PCB Size:
Three section track: 50*50-350*400mm
Single section track: 50*50-450*400mm
PCB Height: Top: 110mm(150mm optional), Bottom:25mm
PCB Thickness: 0.3 ~ 6.0mm
PCB Edge: 3.0mm
PCB Warpage: ±3.0mm
PCB Weight: Max: 10Kg
Conveyor Height: 750&900±20mm
Display: 23.8 inch FHD display
Data output: Autogenerated statistic analysis SPC
Special function: Automatic search of elements and quick programming
Power: AC220 50/60Hz,5A
