Internal Dimension WxHxD (mm): 700x600x600
External Dimension WxHxD (mm): 1700x2100x1750
Temperature Range of Testing zone: -65°C~+150°C (200°C is Optional)
+ (High Temperature Range of Testing Zone: +60°C~+150°C(200°C is Optional)
+ (Low Temperature Range of Testing Zone: -10°C--40°C/-55°C/-65°C)
Exposure Time of High/Low Temperature:
+ Exposure Time of High Temperature:+60°C~+150°C (200°C is Optional) 30Mins
+ Exposure Time of Low Temperature: -10°C ~ -65°C 30Mins
Temperature of Heat-storing Slot/Heating Time: RT-200°C/About 45mins
Temperature of Cool-storing Slot/Cooling Time: RT--75°C/About 100mins
Temperature Recovery Time/ Conversion Time: <5min/s5sec
Precision Temperature Control/ Distribution Accuracy: +0.5°C/+2°C
Cooling System:
+ Semi-hermetic double-stage compreor(Water-cooled Type)
+ Hermetic double-stage compressor (Air-cooled type)
Accessories: Viewing window(special optional)
Compressor: French "Tecumseh Brand, Germany "Bitzer" Brand
Approx. Weight (Kg): 900
