Technical characteristics
Measuring range [relative / absolute]: 0.0001 – 60 % H₂O / 0.01 – 60 mg H₂O
Precision [%] of measuring range end value: ±1.4
Resolution [mg/ppm/%H₂O]: 0.01 / 1 / 0.0001
Temperature range [C °]: 60 - 200
Sample weight [g]: from 0.1
Measurement time [min] depending on material: 10…60
Measurement result: mg, ppm, %
Interfaces: 3xUSB 2.0, 1xEthernet
Electrical data
Rated Voltage [V], depending upon model: 110/115/230 ± 10 %
Power frequency [Hz]: 50/60
Nominal power [W]: 450
Dimensions
Width net [mm]: 510
Height net [mm]: 325
Depth net [mm]: 230
Weight [kg]: 14.2
