Structure: 6 Column (Four Columns Two Ball Screws)
Control Way: Loading Process Manual Control
Max. Load: 1000 KN (100 TONS)
Load Accuracy: ≤±1%
Load Range: 2%~100% FS (20KN~1000KN)
Load Resolution: 0.01 KN
Piston Speed: 0-50mm/min (Manual Adjustment)
Crossbeam Lifting Speed: 120mm/min
Max. Tension Test Space: 650mm (Can Be Customized)
Max.Compression Test Space: 500mm (Can Be Customized)
Center Spacing Between Columns: 600mm
Column Effective Spacing: 525mm
Max. Piston Stroke: 250mm
Clamping Method: Manual Clamping/ (Optional: Hydraulic Clamping)
Round Specimen Clamping Range: Φ13-Φ26mm, Φ26-Φ40mm (Optional: Φ6-Φ13mm, Φ40-Φ50mm)
Flat Specimen Clamping Range: 0-15mm (Optional: 15-30mm)
Flat Specimen Clamping Width: 80mm
Compression Platen Size: Φ 160mm
Span Of Bending Rollers: 450mm
Width Of Bending Rollers: 120mm
Power Supply: 3-phase, AC380V, 50Hz (Can Be Customized)
