Voltage Outputs:
Output Range & Power: 3×265 V ac (L-N)
+ 22.5 VA max each@265V
+ 21 VA max each@200V
+ 12.5 VA max each@100V
+ 7 VA max each@63.5V
+ 6.65 VA max each@57.7V
+ 1.1 VA max each@10V
Accuracy: 0~1V：±2mV
1~VMax：±（0.02%Rd+0.03Rg） Guar
Resolution: 0.001V
Distortion: <0.05%Typ. / <0.1% Guar.
Current Outputs
Output Range & Power: 3×10A ac (L-N)
+ 27 VA max each@10A
+ 25.5 VA max each@9A
+ 24 VA max@8A
+ 17 VA max each@5A
+ 3.88VAmax each@1A
Accuracy: 0~0.2A：±2mA
0.2~IMax： ±（0.02%Rd+0.03Rg） Guar.
Resolution: 0.001A
Frequency & Phase Angle
Frequency Range: DC~1KHz
Frequency Accuracy: ±5ppm
Frequency Resolution: 0.001 Hz
Phase Range: 0°~360°
Phase Accuracy: <0.1° Typ. / <0.2° Guar. 50/60Hz
Phase Resolution: 0.001°
Aux. DC Voltage Source (Battery simulator)
Range: 24V（0.9A）、48V（0.6A）Switchable；
110V or 220V output（/Option）；
Other type can be customized；
Accuracy: 5%Rg Guar.
Binary Input
Quantity: 2pairs
Voltage range: dry contact, input voltage DC 0~300V
Fast Binary Output
Quantity: 2pairs
Circuit Breaker Simulate: Can be define as Open or Close status
Contact performance: Open the dry contact output using opto-coupler relay, the on-resistance is ≤6Ω, and the shut-off withstand voltage is ≤DC350V
SOE test function: the time error between the two outputs is ≤0.2ms, and the SOE resolution test can be performed
Communication
USB2.0 : 1 USB socket, used for software upgrade
Built-in Internal Battery
Battery capacity: 90WH
Work time: standby working time is not less than 8 hours；
5A current output can work for not less than 1 hour;
Charge time: Fast charging, charging time is less than 1 hour
AC/DC Charger
Input: 100~240Vac，50/60Hz，Max2.5A
Output: 33.6Vdc，5.0A（168W）
Environment
Operating Temperature: 0℃~45℃
Storage Temperature: -5℃~50℃
Humidity: <85%RH, non-condensing
Others
Grounding Terminal: 4mm banana socket
Weight: Approximately 35 Kg
Dimensions(W x D x H): 252x95x185(mm)
