Low Pressure Range Model (Default): 0-200 Psig (0-25 Bar)
Other Ranges Available On Request From Scale 0-50 Psig (0-6 Bar) To 0-500 Psig (0-100 Bar)
Pressure Sensor Material: Stainless Steel With Media-Isolated Metal Diaphragm
Pressure Sensor Gas Connection : NPT 1/4
Other Gas Connection Type Available On Request
Pressure Sensor Rated: IP65
Accuracy: +/- 0.25% Full Scale
Operating Voltage: 85 ~ 264 VAC
Operating Current: < 0.1A
Operating Frequency: 50-60Hz
Relay Outputs (4x): Dry Contact N.O & N.C
Relay 1: Status System Working
Relay 2: Source 1 Low Pressure Alarm
Relay 3: Source 2 Low Pressure Alarm
Relay 4: Source 1&2 Low Pressure Alarm With Buzzer
Communication: Serial Port RS232 With Modbus RTU (Male DB9 Connector)
Operating Temperature: -20°C To 70°C (-4°F To 158°F)
Operating Temperature For Pressure Sensors: -40°C To 125°C (-40°F To 257°F)
