Lingke L-HW2807C-3 Hand-Held Welding Machine (28kHz; 750W; Handheld)

Frequency: 28kHz

Power: 750W (Standard/Vertical/Handheld options for 750W)

Input Voltage: AC220V

Oscillation Time: 0.01 - 9.99s

Welding Capability: Φ30mm

Generator Size (750W Handheld): 312 × 193 × 133 mm

Handle Size (Straight Handle): Φ42.5 × 128.5 mm

Net Weight (Generator): _

Frequency Display: Real-time display frequency

Display Screen: LCD full color touch screen

Maximum Output: 10% Higher than rated output frequency

Load Display: Real-time monitoring of current load value during operation

Adjustable Amplitude: 10% to 100% (Digital type)

Operating Temperature: -20°C to +45°C

Non-standard Mode: External control supported

Multiple Protection: Overcurrent, overvoltage, frequency offset, overload, fuse, etc.
