A.Scaleplate: 20 ~ 88HRA, applicable to determination of metal hardness above70HRC (such as hardness alloy, tungsten carbide), hardish thin sheet, and parts after surface treatment
B.Scaleplate: 20 ~ 100HRB applicable to determination of softer metal and non-quenched steel
C.Scaleplate: 20 ~ 70HRC applicable to determination of heat treated steel parts
Initial Test Force: 98.07N (10kgf)
Total Test Force: 588.44N (60kgf) 980.7N (100kgf) 1471N (150kgf)
Max. Height of Test Sample: 170mm
Distance from Intentation Center to Machine: 135mm
Dimension: 466×238×630mm
Net Weight: 65kg
