Mark-10 FS05-2 Tension and Compression Force Sensor (2 lbF / 1000 gF / 32 ozF / 1 kgF / 10 N)

Capacity x Resolution

With Models M7I & M5I indicators

lbF: 2 x 0.001

ozF: 32 x 0.02

gF: 1000 x 0.5

kgF: 1 x 0.0005

N: 10 x 0.005

kN: -

mN: -

Accuracy: ±0.1% of full scale + indicator or test frame

Safe Overload: 150% of full scale

Weight: FS05-012 - FS05-100: 1.2 lb [0.5 kg]; FS05-200 - FS05-500: 1.3 lb [0.6 kg]
