Mode of display: 5" TFT true color LCD industrial touch screen
Form of display: Real-time list, curve (historical curve), bar chart, current alarm (historical alarm), file record list
Query of records: The machine view record curve, historical alarm record, computer software analysis query
Number of channels: Each module supports 8 channels, maximum of 64 channels
Thermoelectric couple: K, J, E, T, N, S, R, B
Basic accuracy: 0.2°C + 2 words (without thermocouple error)
Range of measurement: -200°C to 1820°C (based on the thermocouple indexing range)
Cold end compensation accuracy: ±0.5°C
Resolution correction: 0.1°C, independent error correction per channel, Y = kx + b (x = measured value)
Number of files: 64 (loop records)
File capacity: One file can record 130,000 groups (without distinguishing the number of channels)
USB flash drive interface: Export record file, second change U disk function (instrument acts as U disk), directly view files and software
Recording duration: One-second recording interval can be recorded consecutively for 97 days
Rate of sampling: Fast: 0.1S, Slow: 18S
Isolation between channels: AC/DC up to 350V, high voltage live measurement, super anti-interference ability
Control output: Two sets of independent relay outputs are (H/L) and (HH/LL) relays
Alarm sound: All buzzer sounds (any alarm sounds, can be muted)
Interval of recording: 1 to 9999 seconds, any setting
Communication interface: USB and RS485 ports are standard
Power supply: AC85-265V ±10%, frequency 50Hz/60Hz
Power consumption: <10W
Thermoelectric couple: Each channel is equipped with a 2m K thermocouple
Size: Width 220mm x Depth 293mm x Height (including feet) 106mm (about the size of A4 paper)
Weight: About 3kg (configuration varies)
Environmental conditions: 5~40°C, 20%~80% RH (no condensation)
Datasheet
Catalog
Instrument second change U disk
32 channels can be displayed simultaneously
A one-second interval can also record 97 days
One click fast recording
List, curve, histogram display
Remote Firmware Upgrade
Strong anti-jamming
Record files are exported or deleted at any time
Customize channel names and export EXCEL files
Multistage alarm function, double relay output
Using 8 different thermocouples at the same time
