Gain: 4.75 dBi
Style: T-Bar
Width: 9 mm
Height: 0.7 mm
Length: 40.95 mm
Impedance: 50 Ohms
Cable Type: 50 mm Coax
Technology: WiFi
Unit Weight: 732 mg
Cable Length: 50 mm
Power Rating: 2 W
REACH - SVHC: Details
Mounting Style: Screw Mount
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.85 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: ISM, U-NII
Antenna Connector Type: IPEX MHF
Protocol - GPS, GLONASS: GLONASS, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
