Image Sensor: 752×480 CMOS
Barcodes:
1D: Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, ISSN, Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Databar, AIM-128, ITF-14, ITF-6, Matrix 2 of 5, Industrial 2 of 5, Standard 25, Code 11, Plessey, MSI-Plessey.
2D: PDF417, QR Code, Data Matrix, Chinese Sensible Code.
Resolution: ≥5mil
Depth of Field: EAN-13: 65mm-295mm (13mil). Code 39: 55mm-165mm (5mil). PDF 417: 65mm-135mm (6.7mil). Data Matrix: 65mm-140mm (10mil). QR Code: 45mm-175mm (15mil)
Scan Angle: Pitch: ±50°, Roll: 360°, Skew: ±50°
Minimum Symbol Contrast: 30%
Memory: 1MB (capable of storing the data of over 20,000 EAN-13 barcodes)
Communication Range: 50m/164 ft. (open space)
Wireless Standard: 2.4 - 2.5GHz ISM Band, compatible with Bluetooth 4.0/3.0/2.1+EDR
Connectivity: Micro USB, Bluetooth HID/SPP/BLE Profiles
Current: Operating Standby: 125mA (Bluetooth on) 12mA
Dimensions (L×W×H): 88.0(L)×46.0(W)×24.5(H)mm
Weight: 62g
Notification: Beeper, LED and Vibration
Battery: 3.7V 900mAh rechargeable Li-ion battery
Battery Life: 6 hours continuous operation (Synchronous mode, scan and send data once every 6 seconds)
Battery Charge Time: 3.5 hours
Operating Temperature: -20°C to 50°C (-4°F to 122°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5%~95% (non-condensing)
ESD: ±8 KV (contact discharge); ±15 KV (air discharge)
Drop Resistance: 1.2m
Protection Standard: IP42
