Image Sensor: 800 × 800 CMOS
Illumination: White LED
Decoding Capability:
1D: EAN-8, EAN-13, UPC-A, UPC-E, ISSN, ISBN, Codabar, Standard 2 of 5, Code 128, Code 93, ITF-6, ITF-14, GS1 Databar, MSI-Plessey, Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 11, Plessey, etc.
2D: PDF417, Data Matrix, QR Code, Aztec, Micro QR, etc.
Resolution: ≥4 mil
Scan Mode: Sense Mode, Continuous Mode
Minimum Print Contrast: 25%
Scan Window: 50 mm × 50 mm
Field of View: Horizontal 74°, Vertical 74°
Scan Angle: Roll: 360°; Pitch: ±40°; Skew: ±40°
Dimensions: 67.7 (W) × 47.5 (D) × 78.7 (H) mm (maximum)
Weight: 132 g
Indicators: Beeper, LED
Power Consumption: 869 mW (typical)
Current @5VDC: Operating: 185 mA (typical), 193 mA (maximum)
Interface: RS-232, USB
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5% – 95% (non-condensing)
ESD Protection: ±15 kV (air discharge); ±8 kV (direct discharge)
Protection Rating: IP65
Certifications: FCC Part 15 Class B, CE EMC Class B, RoHS
