Technology: Si
Channel Mode: Enhancement
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel Trench MOSFET
Qg - Gate Charge: 26.6 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 3.8 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Id - Continuous Drain Current: 12 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 16 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 2 V
