Nihon Denji Sokki (NDK) SV-05502 Large Capacity Capacitor Type Magnetizer (CU-1; 500V; 5000µF)

CU-1 digital control unit

Maximum charge voltage: 500V

Capacitance: 5000µF

Power input (*1): Single phase, AC 200V, 15A

Maximum allowance current: 10kA

Charge time (*2): 3s

Reference for external dimensions (*3): 605×785×1035 mm

Reference for mass: 150kg

*1 Options are available for customized specifications of local factory voltages.

*2 Charging time can be adjusted in line with production volumes.

*3 Dimensions: W x D x H. Can be modified to fit installation space (please contact us).
