Light source: Laser diode(>100,000 hours MTBF)
Sensor: Ultra high sensitivity optical sensor
Particle size: 0.5um, 1.0um, 2.5um, 10um
Measuring range: 0-9999ug/m3 and 0-99999999PC/L
Resolution: 1ug/m3 and 1PC/L
Gas detection: With 1~3 gas type (Optional)
Tem/Humidity inspection Temperature: -40 ～ 120℃ ，
Humidity: 0-100%RH
Verification standard: According to GB/T16292-1996 and ISO14644-1
Flow Rate: 2.83 L /min (0.1cfm)
Sample time: 30s
Measuring mode: Quantity mode (unit of PC/L) and quality mode (unit of ug/m3)
Detect methods: Time detecting or circle detection is adjustable
Interface: RS232-USB
Data Storage function: Real-time storage or timing storage is adjustable; Storage capacity of 100000 group data, can check the history data on the counter screen
Print mode: Optional micro-printer, can reset the print period and print mode
Working environment: 5 ～ 45℃, ≤90%RH, non-condensing
Power supply: 4000mA rechargeable lithium battery
Explosion-Proof grade: ExiaⅡ CT4
Protection grade: IP65
Body material: ABS+PC
Size and Weight: 220*85*55 mm (LxWxD), 0.5kg (net weight)
Accessory: Box, data cable, Charger, CD
