Width: 152 mm
Height: 102 mm
Length: 38 mm
Memory: EEPROM
Baud Rate: 9600 to 115200
Isolation: 500 Vac, Output common to System ground
Materials: ABS
Input Type: N/A
Mounting Note: 165 mm on center
Output Signal: Current, Voltage
Data Interface: RS485
Digital Filter: Programmable
Digital Output: 5 mA minimum, 10 mA maximum
Supply Voltage: 10 to 30 Vdc
Voltage Output: 0 to 10 Vdc, ±10 Vdc
Analog I/O Note: Analog Ouput Note: Number of Channels: Two analog outputs (programmable for voltage or currrent output), Voltage Range: 0 to 10 Vdc, ±10 Vdc, Current Ranges: 0 to 20 mA, 4 to 20 mA, Update Rate: 250 conversions per second, Accuracy: ±0.1%, DAC Resolution: 12-bit , Span Tempco: ±25ppm/°C maximum, Settling Time to 0.1% FS: 1 mS, Communications: Watchdog timer, Current Output Compliance: ±12 Vdc, Voltage Output Drive: 5 mA maximum, ADC Analog Output Signal Readback: 8-bit, Isolation: 500 Vac, output common to system ground ,Current Output Burnout: Protected to 250 Vac, Power Requirements: Serial = 2.1W
Conversion Rate: 250 conversions/sec
Pull-up Resistor: 10 kΩ
Output Resolution: DAC: 12-bit
Relative Humidity: 0 to 95% RH non-condensing
Supply Power Note: Power Requirements: Serial = 2.1 W
Supply Power Type: DC
Common Mode Voltage: Input to Output at 115 Vrms, 60 Hz: 500 Vrms
Data Interface Note: Modbus RTU protocol;Configuration Method: Modbus
Output Settling Time: 0.1% FS: 1 ms
Electrical Connection: Screw Terminal
Transmission Distance: 1219 m
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Number of Channels, Output: Analog: 2
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -25 °C
