Width: 3.3 in
Height: 0.95 in
Length: 3.5 in
Weight: 4.1 oz
Software: XP SP3/Vista/7 and 8 (32 and 64-bit)
Baud Rate: 250000
Materials: Plastic
Alarm Note: User configurable audible, on-screen, email and text (SMS) alarms, Alarm Delay: A cumulative alarm delay may be set in which the device will activate the alarm (via LED) only when the device has recorded a user specified time duration of data, Audible Alarm Functionality: 1 beep per second for reading alarm above/below threshold
Input Type: External
Stop Modes: Manual via remote software connection, At set date and time, At set Duration
Calibration: Digital Calibration through Software
Samples,Max: 32256 Samples, Interval Selectable 1 Sec to 24 hrs
Sensor Type: Current Sensor
Start Modes: Delayed Start, Immediate Start
Battery life: 4 yr, typical with reading interval of 15 min
Current, Max: ± 707 mA for 2 Seconds
Display Type: LCD
Memory Modes: Yes
RF Frequency: 2.45 GHz
Configuration: Omega Engineering Data Recording Software, Windows PC
Response Time: Current: 0.15 sec
Time Accuracy: ± 1 minute/month
Band Frequency: 2.405 to 2.475 GHz
Data Interface: Wireless, USB
Conversion Time: 150 milliseconds
Impedance Input: 1 Ω
Nominal Current: 160 mA
Calibration Date: Automated
Measurement Type: Current
LED Functionality: Green LED blinks every 5 seconds to indicate unit is logging, Blue LED blinks every 15 seconds to indicate unit is in wireless mode, Red LED blinks every 1 second to indicate alarm condition
RF Frequency Note: 2.45GHz IEEE 802.15.4 ultra-low power wireless transceiver with fully bi-directional communication
Relative Humidity: 0 to 95% RH non-condensing
Supply Power Note: Max Voltage Between Inputs to Ground: 2.5 V
Supply Power Type: Battery
Current Resolution: 0.01 mA
Response Time Note: Current: 0.15 seconds at sensor
Band Frequency Note: ISM band 2.405 to 2.475 GHz operation (channels 11 through 25) @ 250 kbps data rate
Data Interface Note: USB to mini USB, 250,000 baud for standalone operation or OM-CP-RFC1000-EXT/ OM-CP-RFC1000-EXT-EUR/OM-CP-RFC1000-IP69K required for wireless operation
Frequency Rejection: 50 to 60 Hz
Real Time Recording: The device may be used with PC to monitor and record data in real-time
Calibration Accuracy: Current: ± 0.01 mA
Battery Size and Type: Li-ion, 9V
Number of Measurements: 1
Temperature Coefficient: < ± 50 ppm/°C typical
Current Measurement Range: ± 160 mA
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
