OMRON 61F-LS-CP11-NRA Floatless Level Switch

Fluid Type: Liquid

Applicable Fluids: Ordinary purified water, sewage water (wastewater)

Level Detection Type: Long-distance, high-temperature

Control Applications: Automatic water supply and drainage

Power Supply Voltage: 100…240 VAC

Number of Level Detection Points: 2

Body Material: Plastic

Allowable Connection Distance (between the controller and electrodes): 4 km

Output Type: SPDT (Single Pole Double Throw)

Output Rating (resistive load): 5 A at 250 VAC

Protection Circuit: Short-circuit protection

Mounting Method: Plug-in socket

Electrical Connection Method: Socket

Operating Environment: High-temperature environment

Ambient Temperature (non-freezing and non-condensing): -10…70 °C

Ambient Humidity (non-condensing): 25…90% RH

Weight: 100 g

Overall Width: 38 mm

Overall Height: 49.4 mm

Overall Depth: 84 mm
