OMRON G3PH-5075B 5-24VDC High-power Solid State Relay (1 phase, 5-24VDC)

Application: ON/OFF control

Number of phases: 1

Number of poles: 1

Mounting method: Screw

Terminal: Screw

Complete with socket: X

LED indicator: ✓

Rated operational voltage, AC: 180-480 V

Operating voltage range, AC: 150-528 V

Rated operation current Ie at AC-1: 75 A

Supply voltage DC: 5-24 V

Control current max.: 5 mA

Must operate voltage max.: 4 V

Must release voltage min.: 1 V

Maximum operating temperature: 80 °C

Minimum operating temperature: -30 °C

Isolation: Photocoupler

Switching at zero-crossing: ✓
