OscarMax SD400 ZNC Plus Micro Drill Electrical Discharge Machine (990 x 460 mm, 4.6KVA)

Table Travel (X): 400 mm

Table Travel (Y): 300 mm

Servo Travel (W): 345 mm

Guide Travel: 200 mm

Manual Guide Travel: 150 mm

Max. Workpiece Dimensions (WxD): 990 x 460 mm

Guide (30mm) to Work Table: 5-355 mm

Max. Workpiece Weight: 450 kg

Table Size (WxD): 600 x 300 mm

Machine Weight: 1200 kg

Generator

Max. Working Current: 50A

Overall Power Consumption: 4.6KVA

Dielectric

Tank Capacity: 60 L

Filter Density: 10 μm

Filter Elements: 2 pc
