PHOENIX CONTACT 3000715 멀티 레벨 터미널 블록 PTTB 2,5-PV BU

Color: Blue

Width: 5.2 mm

Height: 47.5 mm

Length: 68 mm

Unit Weight: 10.270 g

Current Rating: 22 A

Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)

Voltage Rating: 500 V

Wire Gauge Max: 12 AWG

Wire Gauge Min: 26 AWG

Housing Material: Polyamide (PA)

Connection Method: Push-In

Flammability Rating: UL 94 V-0

Number of Positions: 4 Position

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 60 C
