Color: Gray
Width: 8.2 mm
Length: 83.5 mm
Unit Weight: 17 g
Current Rating: 32 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 1 kV
Wire Gauge Max: 10 AWG
Wire Gauge Min: 24 AWG
Wire Gauge Range: 24 AWG to 10 AWG
Connection Method: Push-In
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
