PHOENIX CONTACT 3208130 피드스루 PT 1 5/S YE

Color: Yellow

Width: 3.5 mm

Height: 30.5 mm

Length: 45 mm

Unit Weight: 3.710 g

Current Rating: 17.5 A

Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)

Voltage Rating: 500 V

Wire Gauge Max: 14 AWG

Wire Gauge Min: 26 AWG

Wire Gauge Range: 26 AWG to 14 AWG

Connection Method: Push-In

Number of Positions: 2 Position

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 60 C
