Applications
+ Sterility test isolators
+ Filling lines
+ Aseptic transfers
+ Biotech applications (product to patient, in the OR)
+ Troubleshooting contamination events
Minimum resolution 1 Bio-Count (representative of 1 CFU)
Maximum concentration 25,000 Bio-Counts per second
Size range 0.5 μm to 50 μm
Sizing channels Two-size Channel Mode
Size 9.84 x 7.87 x 5.91 in (25 x 20 x 15 cm) (Box without ISP and handle)
Weight 13.5 lb (6.1 kg)
Operation temperature 32 – 95 °F (0 – 35 °C), 10 – 95% non-condensing relative humidity
Storage temperature 14 – 140 °F (-10 – 60 °C), 10 – 95% non-condensing relative humidity
External chemical resistance Isopropyl alcohol, acetone, chlorinated solution, hydrogen peroxide
Enclosure material 316L stainless steel
Flow rate 3.6 LPM ± 5%
Power source 85 – 264 VAC, 47 – 63 Hz
Power consumption 15 W
Air outlet filtering HEPA filter provided (> 99.97% @ 0.3 μm)
Detectors Photo Multiplier Tube (PMT)
Laser wavelength 405 nm
Data storage External software: Pharmaceutical Net, FacilitySight, or customer-supplied
Communications RS-232 and TCP/IP via Ethernet
