Maximum discs/skirts per insulator string: 55 discs per insulator string
Minimum discs/skirts per insulator string: 4 discs per insulator string
Maximum corona protection: 1 million Volts
Minimum electrical field: 10 kV/meter
Maximum memory capacity: 300 strings of insulators or 15,000 readings, whichever comes first
Maximum scanning speed: 6 discs per second
Maximum time between uploading of cumulative data: 12 days
Maximum time between battery charges: 12 hours
Minimum time of battery recharging: 10 hours (one night)
Time tag update interval: 16 seconds
Operating temperature range for the probe: -22°F to 122°F (-30°C to 50°C)
Operating temperature for the logger: 32°F to 122°F (0°C to 50°C )
Dimensions W: 14” x H: 19” x D: 9” (35.5 x 48 x 23 cm)
