Gain: 2.1 dBi, 3.1 dBi, 4.4 dBi
VSWR: 2.5:1, 2.1
Style: Straight
Length: 77.2 mm
Diameter: 40.9 mm
IP Rating: IP67
Impedance: 50 Ohms
Application: Transportation, Utility Boxes
Unit Weight: 120 g
Power Rating: 10 W
Mounting Style: Direct / Permanent Mount
Number of Bands: 2 Band
Center Frequency: 830 MHz, 2.2 GHz
Mechanical Style: Whip
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: N Female
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
