Gain: 2.7 dBi, 1.5 dBi, 1.6 dBi, 3.2 dBi, 3.6 dBi, 4 dBi
Style: T-Bar Flex
Width: 26.8 mm
Height: 0.8 mm
Length: 120.4 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Application: Security, Video, Graphics, IoT Devices, Smart Grid, Meters, Remote Monitoring, Sensor Networks, Transportation, Tracking, Radio Modules, RF Environments
Unit Weight: 2 g
Cable Length: 139 mm
For Use With: W3907B0100
Polarization: Linear
Power Rating: 3 W
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 750 MHz, 868 MHz, 900 MHz, 1469 MHz, 1575 MHz, 1602 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2500 MHz, 3500 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 3.6 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: U.FL
Protocol - GPS, GLONASS: GNSS
Protocol - WiFi - 802.11: WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
