Range(bar): 0 to 400
Resolution(bar): 0.01
Units: bar, psi, Kg/cm2, KPa, MPa, atm, mH2O, inHg, ftH2O
Comparator range: CP-400S (0 to 400)
Over Pressure Alarm: 20% of Full Scale (up to 40 bar), 5% of Full Scale (for other ranges)
Pressure Media: Compatible with 316 Stainless Steel Current Terminal
Input Protection: Fuse 100mA / 250V
Display: Graphical display with LED backlight
Power Supply: Li-ion rechargeable battery
Transmitter Supply: 24V DC ±10% (Loop Powered)
Battery Backup: Up to 19 hours
Low Battery Indicator: Yes
Auto Power Off: After 15 minutes of inactivity
Pressure Connection: 1/4" BSP Female
Operating Temperature: 10 to 50°C
Instrument Casing: ABS Plastic
Dimensions: 250 mm x 145 mm x 45 mm (L x W x D)
Weight: 650 grams
