Bandwidth: 1 GHz
Channels: 4 analog channels + 1 EXT channel
Sample rate: 4 GSa/s
Rise time: ≤350 ps (single-channel & half-channel), ≤440 ps (full-channel)
Memory Depth: 500 Mpts (single-channel & half-channel), 250 Mpts (full-channel)
Sampling Mode: Real-time Sampling
Maximum Waveform Capture Rate: 200,000 wfms/s (in Vector mode); 1,000,000 wfms/s (in Record mode)
Maximum Frames of Waveform Recording: Maximum 500,000 frames
Peak Detection: Captures 500 ps glitches
LCD Size and Type: 10.1" capacitive multi-touch screen
Display Resolution: 1280 x 800 pixels
