RIGOL PLA2216 High-performance Active Logic Probe (16 CH, ±15 V, 101 kΩ)

Input channels: 16

Threshold range: ±15 V

Threshold accuracy: ± (100 mV + 3% of threshold setting)

Max input voltage: ±40 V (peak)

Max input dynamic range: ±10 V + threshold setting

Min voltage swing: 500 mVpp

Min detectable pulse width: 5 ns

Input impedance: About 101 kΩ

Input capacitance: About 8 pF

Cable length: About 90 cm

Lead length: About 25 cm

Operation environment: 0℃~50℃, 0~80%RH

Storage environment: -20℃~60℃, 0~90%RH
