Run Test RUN-HDCR10A Transformer Test equipment Winding Resistance Meter DC Resistance Tester

Display Type: Digital Only

Measuring Range: 0.01–2000 micro ohms

Testing Voltage: 220V

Accuracy Class: 0.2%

Operating Temperature: 0℃~+40℃

Dimensions: 252×160×60mm

Name: DC Resistance Tester

Max Frequency: (50±1)Hz

Ambient Humidity: ≤85%RH

Certificate: ISO, ICE

Accuracy: 0.2%

Weight: 2.0kg

Size: 252×160×60mm

Feature: Self-discharge and discharge alarm

Product Type: Handheld

Standard Accessory: USB Line

Used for checking the welding quality of the winding joints and whether the windings have inter-turn short circuits, check whether the contact of each position of the voltage tap switch is in good condition, whether the actual position of the tap changer matches the indicated position, whether the lead wire is broken, and the multi-stranded wire is wound in parallel. Whether there is stock breakage, etc.

1. Light weight, small size

2. Large output current, good repeatability

3. Strong anti-interference ability

4. high degree of automation

5. High test accuracy

6. Easy operation
