Schaefer SealLine 240-1 ADVANCED Crimping Machine (0.2 - 4.0 mm², 20 kN)

Wire

Single cores or multi-core cables (one after the other)

Wire cross section: 0.2 - 4.0 mm²

Cable outer diameter: Max. 5 mm

Sheath-removal length: Min. 25 mm

Seals :External dimensions: Max. Ø 17 mm, max. length 16 mm

All common seal types as well as hard shell seals

Terminals :Transversely belted stripes

Processing

Zero cut lengths :1 - 3 mm

Stripping lengths: 0.5 - 8.0 mm

Performance and geometry

Drive: 0.75 kW three-phase motor

Motor speed :440 - 2000 rpm

Pressing force :20 kN

Stroke: 40 mm

Closing height :135.78 mm

Controls

Software :STI 2015

Display and operation :Touchscreen

Supplies and interfaces

Power supply :230 V, 50/60 Hz

Compressed air: 6 bar

Network: RJ-45

Dimensions and weight

Width x Depth x Height :1050 x 850 x 1500 mm

Weight :225 kg
