Indentor: Ball Ø 10 mm
Area of application: For loosely wound bobbins of thick yarns, such as carpet yarns
Depth of indentation*: 0 – 2.5 mm
Test pressure**: Approx. 12.5 N
Measuring spring force*: 0.55 – 8.065 N
Display range: 0 – 100 hardness graduation marks
Scale diameter: 54 mm
Working face radius: 55 mm
Weight, net (gross): Approx. 300 g (500 g)
Dimensions: 50 x 58 x 110 mm (LxWxH)
* Meets requirements of Shore A
** Spring load of outer ring to create constant pressure when outer ring is pulled to red marking
