Schwarzbeck BBHA 9120 B Broadband Horn Antennas (1.5 ... 10 GHz)

Nominal Frequency Range: 1.5...10 GHz z

Usable Frequency Range: 1 ... 10.5 GHz

Isotropic Gain: 5 ... 18 dBi

Antenna Factor: 25 ... 33 dB/m

Nominal Impedance: 50 Ω

Standing Wave Ratio SWR typical: < 1.5

Standing Wave Ratio SWR max.: < 2.5 (f > 1.5 GHz)

Front to Back Ratio: typ. > 25 dB (f > 1.3 GHz)

Cross Polarisation: typ. > 25 dB

3 dB Beamwidth typ. (E-Plane): ≈ 34°

3 dB Beamwidth typ. (H-Plane): ≈ 32°

Max. Input Power: 300 W (cont.)

N-Connector female

Mount: 22 mm Tube, Indexing Ring

Width x Length x Thickness: 184 x 272 (480) x 128 mm

Weight: 1.2 kg
