Schwarzbeck HFRA 5154 Transmit Loop Antenna for Calibrations (0.1 – 30 MHz)

Frequency Range: 0.1 – 30 MHz

Impedance: 50 Ω

VSWR: < 1.3

Number of Turns: 2

Current Transformation Ratio: 2:1

Loop Diameter: 100 mm

Maximum Current: 100 mA / 100 dBµA

Maximum Voltage: 5 V / 134 dBµV

Maximum Power: 0.5 W / +27 dBm

Mechanical Dimensions: 160 × 112 × 62 mm

Terminals: BNC

Mount: 3/8"

Weight: 250 g
