Switch: without
valve: ABS, CW614N
Nominal width: DN 4
Process connection: female thread 1/8 “ NPT
Metering range: 0.10 - 1.0 Nl/min for details see
Qmax recommend: 1.2 Nl/min
Tolerance: ±5 % of full scale value
Pressure resistance: PN 6 bar
Medium temperature: -20..+65 °C
Ambient temperature: -20..+65 °C
Media: gases
Electrical data: none
Materials medium-contact
Brass construction: acrylic, glass, 1.4305, 1.4310, CW614N, NBR
Non-medium contact materials: acrylic, CW614N, PS
Weight: 0.13 kg
Installation location: vertical inwards flow from below
For details please see Datasheet
