DC Voltage: 200mV-1000V
DC Current: 200μA-10A
AC Voltage: True-RMS, 200mV-750V
AC Current: True-RMS, 200μA-10A
2/4-Wire resistance: 200Ω-100MΩ
Capacitance: 2nF-100mF
Continuity test: Range is fixed at 2kΩ
Diode Test: Adjustable range is 0-4V
Frequency measurement: 3Hz-1MHz
Period measurement: 1μs-333.33ms
Temperature: Support for TC and RTD sensors
Display: 4.3” TFT-LCD, 480*272
Reading resolution: Real 6½ digits readings resolution (2,200,000 counts)
Size: 1 Gb Nand Flash
Standard Interface: USB Device, USB Host, LAN
Optional Interface: USB-GPIB Adapter and Scanner Card SC1016
Scanner Card SC1016: Support
Standard accessories
Power Cord: 1
USB Cable: 1
Quick Start: 1
Calibration Certificate: 1
