Main control unit: high-performance Embed Computer
Display: 640×480 High brightness TFT Panel
Input: Keyboard
Storage: 1G (Internal)＋2G (U-Disk)
Interface: USB
Receive channel: One
Max sample data length: 64k
Trigger mode: Continuous trigger, External trigger
Trigger voltage (V): 65, 125, 250, 500, 1000 selectable
Receive sensitivity: ≤30μv
Amplifier gain: 82dB
Amplifier bandwidth: 5KHz~500kHz
Sample Periods: 0.05μs~6.4μs，8 grades electable
Sound time accuracy: 0.05μs
Amplifier resolution: 0.39%
Power
- Interior lithium battery，work more than 6 hours
- External lithium battery，work more than 6 hours (select)
- Weight: 1.75kg (include lithium battery)
- DC 12V
- AC 100V~240V, 50/60Hz
Size: 260mm×185mm×60mm
Temperature: -10℃~+40℃
Performance
- High efficient testing. Lifting speed is more than 60m/s.( 20 cm distance )。
- Display the test data graphically. User can watch analyze result directly；
- Fast and precise Automatic judge the sound parameters. Real-time wave display to assure test efficiency;
- Humanized software design. Software design apply to User and construction plant. its help information ensure user handle easily；
- Linking the rebound apparatus directly. Detecting strength of concrete by ultrasonic-rebound combine method with linking rebound apparatus directly，and get strength of concrete in time. The functions apply for national patent.
- Being sensitive to receiving signal. Can receive signal more than 10m in concrete without defects
- Can supply smooth power for radial energy transducer needless external power.
- Standard USB storage with big capacity.
- Interior lithium battery supply power for apparatus work more than 6 hours.
- Portable, small, light apparatus (1.75Kg).
- Extending function for testing thickness of concrete by impacting echo method.
- Professional and powerful analysis software on windows system. It can export the data to Excel or word for advanced analysis
