Open output voltage: 0.5 to 6kV ±5%, min 0.1kV.
Pre-wave time: 1.2μs ±30％
Pulse half peak time: 50μs ±20％
Short-circuit output current: Up to 3kA ±5%
Pre-wave time: 8μs ±20％
Pulse half peak time: 20μs ±20％
Output polarity: Positive and negative
Output impedance: 2Ω±10％
Surge trigger mode: Sync or asynchronous; Surges inject phase
Free set 0-360 degrees, resolution 1 degree
The way the surge is triggered: Automatic or manual, triggered at a single time
The number of surges: 1-9999 times
Surge interval time: 20-9999s
Built-in network capacity:
- AC: Single-phase 300V, 10A (Max), 50/60Hz
- DC: 300V, 10A (Max)
Built-in network coupling
- Line-Line (L-N)
- Line-ground (L-PE, N-PE)
Built-in network-coupled devices
- Line-line
- 18'F capacitor
- Line-ground
10-o resistance s.9 s. capacitor
Use the environment: Temperature: 10%-75% relative humidity at 15C-35C
System power: AC220 ± 10%, 50/60Hz, approx. 300W
Form factor: 470mm wide× 260mm high× 500mm deep
Weight of the whole machine: About 25kg
Product standards:
- GB/T 17626.5
- GB 18802.1
- IEC/EN 61000-4-5
- IEC/EN 61850-3
- ITU-T K.12
- ITU-T K.20
- ITU-T K.45
- UL1449
