Measuring range:
0. 01-600.00 g/10min (MFR)
0. 01-600.00 cm/10min(MVR)
0.001-9.999 g/cm (melt density)
Temperature range: 50-400℃
Temperature precision: ±0.5℃, resolution: 0.1℃
Material canister inside diameter: 9.55±0.025mm, length: 160mm
Piston diameter 9.457±0.01mm, mass: 106g
Mould inside diameter: 2.095mm, length: 8±0.025mm
Load: full load
Weights: 0.875Kg, 1.290Kg, 1.835Kg, 3.475Kg, 4.675Kg, 5.000Kg, 5.000Kg one each (may freewill combination )
Accuracy: 0.5%
Cleaning accessories: clear material pole
Calibration accessories: water level bubble
Measuring method: MFR MVR/ DENSITY
Supply Power: 220V±10% 50Hz Heat up power: about 550W
Outline size: (length*width*height) 600*400*500 (unit: mm)
Net weight: 85Kg, Gross weight: 135Kg
Packing list:
Mainframe: one
Base weight: one
Weight: one (six sort’s seven pieces)
Piston: one
Mould: one
Oriented sheath: one
Water level bubble: one
Hopper: one
Clear material pole: one
Mould bore: one
Material check: one
Provide English explanation : one each
Optional accessory: Balance AR124CN
