Laser Type: MOPA Pulsed Fiber Laser
Power Consumption: ≤2000W
Operating Ambient Temperature: 5–40℃
Operating Ambient Humidity: ≤80%
Average Power: ≥500W
Power Instability: <5%
Pulse Width: 30–500ns
Energy Density (254mm field reference value): 12J/cm²
Maximum Pulse Energy: 15mJ
Power Adjustment Range: 0–100%
Pulse Frequency Range: 1–4000kHz
Cable Length: 5 meters (Customizable 30 meters)
Laser Wavelength: 1064nm
Host Cooling System: Air-cooling
Dimension: 580×262×552mm
Weight: ~30kg
Operating Mode: Handheld/Automated (Platform or Robotic Arm)
Handheld Torch Weight: ~1.25kg (Water-cooling)
Scanning Width: 175mm
Scanning Speed: 10000mm/s
F-Theta Lens Focal Length: F=254mm (Optional: F=160mm, F=330mm)
